Darlly oil filter oil filter element membrane filter cartridge
General Description:
MFF Series Pleated Filter cartridges are manufactured to exact standards and are used in the most demanding industrial environments. Manufactured in a range of length options and micron ratings. Media has a fixed pore construction of high quality fibers. The combination of surface and depth filtration provides a long lifetime. Due to use of the premium quality filter fabrics, the pleated filter cartridges have superior flow characteristics with very low pressure drop compared to depth media of similar micron rating. Due to large filter area and design, allow the use of a reduced number of cartridges. Your advantage is a smaller filter vessel, less footprint and lower capital investments. The pleated cartridges have a very large filtration area and therefore a very high dirt-holding capacity. Long cartridge lifetime means lower operational consumable costs, Less work changing the cartridges and less waste.
Applications:
Features:
- Large filter area and depth filtration provides a long lifetime of pleated filter cartridge.
- Low cost because of large filter area and reduces labor costs to change
Specifications:
Dimensions
- Outside Diameter:69mm
- Inside Diameter:28mm
- Length:10",20",30",40"
Material Of Constructions
- Filter Media: PP,PET, Glass Fiber
- End Cap Material: PP , ABS
- Center Core: PP, ABS
- Netting: PE
- Seal Material: Silicone, EPDM, NBR, VitonEnd Cap Types:DOE,-226/Flat End
Performance
- Removal Rating: 1μm,2μm,5μm,10μm,20μm,50μm
- Operating Pressure and temperature:
- The pleated cartridge construction will withstand differential
- Pressures up to 60 PSI(4Bar) at ambient temperature.
- The optimum changeout differential pressure is 35psi(2.5Bar) up to 52° C.
- Service condition:
- 500KPa(5Bar)by 20° C
- 300KPa(3Bar)by 65° C
General Description:
MFF Series Pleated Filter cartridges are manufactured to exact standards and are used in the most demanding industrial environments. Manufactured in a range of length options and micron ratings. Media has a fixed pore construction of high quality fibers. The combination of surface and depth filtration provides a long lifetime. Due to use of the premium quality filter fabrics, the pleated filter cartridges have superior flow characteristics with very low pressure drop compared to depth media of similar micron rating. Due to large filter area and design, allow the use of a reduced number of cartridges. Your advantage is a smaller filter vessel, less footprint and lower capital investments. The pleated cartridges have a very large filtration area and therefore a very high dirt-holding capacity. Long cartridge lifetime means lower operational consumable costs, Less work changing the cartridges and less waste.
Applications:
Features:
- Large filter area and depth filtration provides a long lifetime of pleated filter cartridge.
- Low cost because of large filter area and reduces labor costs to change
Specifications:
Dimensions
- Outside Diameter:69mm
- Inside Diameter:28mm
- Length:10",20",30",40"
Material Of Constructions
- Filter Media: PP,PET, Glass Fiber
- End Cap Material: PP , ABS
- Center Core: PP, ABS
- Netting: PE
- Seal Material: Silicone, EPDM, NBR, VitonEnd Cap Types:DOE,-226/Flat End
Performance
- Removal Rating: 1μm,2μm,5μm,10μm,20μm,50μm
- Operating Pressure and temperature:
- The pleated cartridge construction will withstand differential
- Pressures up to 60 PSI(4Bar) at ambient temperature.
- The optimum changeout differential pressure is 35psi(2.5Bar) up to 52° C.
- Service condition:
- 500KPa(5Bar)by 20° C
- 300KPa(3Bar)by 65° C
| Code* | Removal Rating | Code= | Length | Code# | Media | Code+ | Seal Material | Code& | Code |
| 1 | 1µm | 10 | 10" | PP | Polypropylene | S | Silicone | F | DOE |
| 2 | 2µm | 20 | 20" | GF | Glass Fiber | E | EPDM | T | 222/Flat End |
| 5 | 5µm | 30 | 30" | PET | Polyester | B | NBR | ||
| 10 | 10µm | 40 | 40" | V | Viton | ||||
| 20 | 20µm | ||||||||
| 50 | 50µm |
